CRH-5 Relative Humidity Transmitter series
原廠目錄下載
(PDF Format, 2 pages,
1366 KB.)
CRH-5
RH & Temperature Transmitter
The CRH-5
relative humidity transmitter series employs an economical
capacitive polymer sensor which performs well over a broad
temperature range. It is ideally suited for high-volume applications
which require low-cost monitoring while offering excellent
performance.
Sensing Element
Porous, thin gold electrodes are deposited over a humidity sensing
polymer allowing for rapid diffusion of the sensed water vapor. This
permits the water to enter and leave easily providing for good
response to changes in humidity.
Features
|
±5% Accuracy |
|
20 to 90% Relative Humidity |
|
0 to 140º F Temperature (Optional) |
|
Two-Wire Loop Powered Transmitter |
|
Low-Cost Design |
|
Innovative Packaging for Improved Performance |
|
Quick Connects for Power and Signal Output |
|
Three Wire Screw Terminals |
|
Reverse Polarity Protected |
Applications
|
HVAC/Building Controls |
|
Energy Management Systems (EMS) |
|
Enthalpy Control |
|
Indoor Air Quality (IAQ) |
|
Clean Rooms |
|
Museums/Archives |
|
Hospitals/Labs |
|
Refrigeration Control |
|
Pharmaceutical |
|
Swimming Pools |
|
Animal Rooms |
|
|
SPECIFICATIONS
Sensing Element: Organic
Polymer RH Capacitive sensor
Optional: Thermistor temperature (10 k ohms)
PERFORMANCE Accuracy: ± 5% RH. at 25ºC(77ºF) Drift rate: Less than 1% drift per year typical
Hysteresis:
Less than 1% RH
Air Velocity Across Transmitter:
Maximum: 10,000 fpm
Minimum: 150 fpm Signal
Outputs: 4 to 20mA, 0 to 5 volts, 0 to 10 volts, (0 to 100% RH linear).
OPERATING RANGE:
Humidity: 0 to 99% operating
Temperature: 0 to 140ºF.
POWER SUPPLY: Supply voltage: 10
to 28 VDC (Current).
Supply voltage: 15 to 28 VDC
(Voltage). Maximum
load (Current Output Only): ohm =
Supply
–10VDC/.02 Amps Storage
temperature: -40ºF to+158ºF.
Ordering Information
-
CRH-5-201-HW: 20 to 4 mA output
-
CRH-5-41-HW: 4 to 20 mA output
-
CRH-5-5V-HW: 0 to 5 V output
-
CRH-5-10V-HW: 0 to 10 V output
|
